CEAG emergency light 1984 1-8h/D LED CGLine+ LED emergency light

Single battery light including foil unit with test button and colored LEDs for differentiated status display for autonomous operation or for connection to the central monitoring device CGLine+. Automatic function test (weekly) and automatic operating time test (every 3 months). 1 minute switch-back delay after power is restored. Blocking function via central monitoring device for idle times. Permissible temperature range: permanent light -5°C to +30°C / standby light 0°C to +35°C. The pictogram disc is not included in the scope of delivery and must be ordered separately. Mounting type: Ceiling mounting Light source: LED Lamp power: 6.7 W Housing material: Steel Housing color: white Type of marking: one-sided/two-sided Suitable for marking type: Acrylic glass plate Monitoring device: automatic self-test Ball-proof: No Switching type: Maintained/standby With remote switch connection (VDE 0100-718,0108-100): Yes Power supply: decentralized (single battery) Nominal voltage: 220 - 240 V Protection class: I Protection type (IP): IP20 Nominal operating time: 3 h With light source: Yes Length: 337 mm Width: 50 mm Height/depth: 96 mm Luminous flux in emergency operation: 22 % Detection range: 28 m
