CEAG emergency light FlexiTech ED AT 8h LED emergency light

In stock
SKU: 898762
€88.67
Into a basketIn the basketGo

Overview

Mounting type: Wall mounting/ceiling mounting Function: Escape route marking Suitable for type of marking: Insert sheet/plate Type of marking: one-sided/two-sided With pictogram: yes Monitoring device: automatic self-test Switching type: Maintained switching/standby switching With remote switch connection: yes Feed: decentralized (single battery) Battery type: lithium-ion Light source: LED not replaceable With light source: yes Suitable for number of light sources: 1 Socket: without Number of light heads: 16 Housing material: plastic Housing color: white Cover material: transparent plastic Voltage type: AC Nominal voltage: 230 V Operating device: not required Light distributor: diffuser lens/optics/panel Energy efficiency class of the permanently installed light source: A++, A+, A (LED) Rated service life L70/B10 at 25 °C: 54000 h Protection class (IP): IP43 Impact resistance: IK07

PropertyValue
Housing color:white
Protection rating (IP):IP43
Protection class:II
Voltage type:AC
Nominal voltage:220 to 240 V
Detection range:20 m
Color temperature:6500 K
Length:228 mm
Width:120 mm
Height/Depth:34 mm
Max. System performance:2 W
Battery type:Lithium-ion
Nominal operating time:1 to 8 h
Rated luminous flux according to IEC 62722-2-1:60 lm
Light source:LED not replaceable
Impact resistance:IK07
Socket:without
With remote switch connection:no
Cover material:Transparent plastic
Installation width:130 mm
With light source:yes
Installation length:245 mm
Monitoring device:automatic self-test
Housing material:plastic
Type of marking:one-/two-sided
Suitable for type of marking:Insert sheet/plate
Feed:decentralized (single battery)
With pictogram:yes
Suitable for number of light sources:1
Number of Lamp heads:1
Light distributor:Diffuser lens/optics/panel
Luminaire with limited surface temperature D-mark according to EN 60598-2-24:no
Power factor:0.4
Installation height/depth:50 mm
Number of poles:3
Conductor cross-section:2.5 mm²
Connection type:Plug connection

Characteristics

HABFlexiTech ED AT 8h
ManufacturerCEAG Notlicht
HANFT2ED4IATL18
GTIN3660191806828
Connection typePlug connection
Rated luminous flux according to IEC 62722-2-160lm
Width120 mm
Installation width130 mm
Installation height/depth50 mm
Installation length245 mm
Color temperature6500K
VersionWithout
Suitable for number of light sources1
Housing colorWhite
Height/Depth34 mm
Power factor0.4
Conductor cross-section2.5 mm²
Luminaire with limited surface temperature D-mark according to EN 60598-2-24No
LampsLED not replaceable
Light distributorDiffuser lens/optics/panel
Length228 mm
Max. system performance2W
With light sourceYes
Nominal voltage220 to 240 V
Number of poles3
Impact resistanceIK07
IP protection)IP43
Protection classII
Voltage typeAC
Cover materialPlastic transparent
Housing materialPlastic
CEAG emergency light FlexiTech ED AT 8h LED emergency light
CEAG emergency light FlexiTech ED AT 8h LED emergency light
€88.67
Into a basketIn the basketGo
