HABMicropoint2 3h MTD Open C/W Intellem
HANMP2O3HIS
GTIN5018987039109
Connection typeScrew connection
Type of wiringSuitable for through wiring
Outer diameter90 mm
Rated luminous flux according to IEC 62722-2-1153lm
Rated ambient temperature according to IEC 62722-2-15 to 35 °C
Operating deviceLED control gear current controlled
Width290 mm
Installation diameter64 mm
Installation height/depth63 mm
Color temperature6200K
VersionWithout
Suitable for number of light sources1
Housing colorWhite
Height/Depth30 mm
Power factor0.5
Conductor cross-section2.5 mm²
Luminaire with limited surface temperature D-mark according to EN 60598-2-24Yes
LampsLED not replaceable
Light distributorFocus lens
Length230 mm
Max. system performance2.5W
With light sourceYes
Mounting typeInstallation
Nominal voltage220 to 240 V
Number of poles4
Impact resistanceIK04
IP protection)IP44
Protection classII
Voltage typeAC
Cover materialOther
Housing materialPlastic
