Cellpack 169477 SEH4 60-25 shrink distribution cap

In stock
SKU: 900434
€23.22
Into a basketIn the basketGo

Overview

Sealing distribution cap for plastic, rubber and paper-insulated cables. Areas of application: Indoors, outdoors. Properties: Stabilized against UV rays, free from substances that impair paint wetting, halogen-free, absolutely moisture-proof, pressure-tight, very good electrical properties, very good mechanical properties. Scope of delivery: Heat-shrink distribution cap.

PropertyValue
Operating temperature:-40 to 100 °C
Inner diameter of finger after shrinking:6 mm
Inner diameter of finger before shrinking:25 mm
Shaft diameter before shrinking:60 mm
Shaft diameter after shrinking:25 mm
Total length after shrinking:177 mm
Nominal cross section:35 to 150 mm²
Design:for 4-core cables and wires
Type:Heat shrink

Characteristics

HABSEH4 60-25
ManufacturerCellpack
HAN169477
GTIN4010311041216
VersionFor 4-core cables and wires
Operating temperatur-40 to 100 °C
Nominal cross section35 to 150 mm²
TypeHeat shrink
