Modular switching, control and plug-in devices as well as accessories for the CHORUS switch range
| Property | Value |
| Version: | Italian type P17/11 |
| Number of units: | 1 |
| Color: | black |
| Suitable for protection class (IP): | IP41 |
| Rated voltage: | 250 V |
| Rated current: | 16 A |
| Lockable: | no |
| With increased contact protection: | yes |
| With hinged lid: | no |
| Mounting type: | Module carrier |
| Text field/labeling area: | no |
| Frequency: | 50 Hz |
| Ejection mechanism: | no |
| Halogen-free: | no |
| Overvoltage protection: | no |
| Residual current protection: | no |
| Special power supply: | without special power supply |
| Twisted central insert: | no |
| Connection type: | screw terminal |
| With fine fuse: | no |
| Mounting type: | snap-on fastening |
| Material: | plastic |
| Material quality: | Thermoplastic |
| Surface: | untreated |
| Surface finish: | matt |
| Number of modules (with modular construction): | 1 |
| Device width: | 22 mm |
| Device height: | 44 mm |
| Device depth: | 25 mm |
| Insulated installation: | yes |
| With Loop-through function: | no |
| With on/off switch: | no |
| With built-in USB power supply: | no |
| With function lighting: | no |
| With orientation lighting: | no |
| Transparent: | no |
| Protective contact: | yes |
| Round protective conductor contact: | yes |
| Number of active contacts (round): | 2 |
| With signal lamp: | no |
| Number of phases: | 1 |
| Antibacterial treatment: | no |
| Min. depth of device box: | 35 mm |
