Gewiss GW44004 100x100x50 IP55 6 cable ends M25 650°C junction box

Gewiss GW44004 100x100x50 IP55 6 cable ends M25 650°C junction box

In stock

SKU: 657219

Price on request

€4.49

€0

Into a basketIn the basketGo

Overview

Square junction box with cable grommets, closed flat screw cover with stainless steel screws.

Property	Value
Width:	120.50 mm
Length:	120.50 mm
Depth:	58 mm
Color:	gray
Protection class (IP):	IP55
Number of entries:	6
Halogen-free:	yes
Equipment:	without
Mounting type:	Wall/ceiling mounting
Material:	Plastic
Cover fastening:	screwed
Sealable:	no
Can be arranged in rows:	no
Shape:	square
Type of Housing feedthrough:	Step membrane can be cut off
For Ex-Zone Gas:	without
Functional integrity:	without
Explosion-tested version:	no
Potable compound supplied:	no
Potable:	no
For Ex-Zone Dust:	without
Installation under water:	no
Transparent cover:	no
Installation in the ground:	no
Surface:	untreated
For pipe diameter:	other
With shielding:	no
Introduction from the rear:	no
Weatherproof:	no
Cover design:	blind cover
Operating temperature:	-25 to 60 °C

Characteristics

Explosion-tested versionNo

HAB100x100x50 IP55 6 cables M25 650°C

Manufacturer

HANGW44004

GTIN8011564013698

Cover designBlind cover

Width120.50 mm

Operating temperature-25 to 60 °C

Color

ShapeSquare

Functional preservationWithout

Halogen freeYes

Length120.50 mm

Mounting typeWall/ceiling mounting

SurfaceUntreated

IP protection)IP55

Depth58 mm

MaterialPlastic

Gewiss GW44004 100x100x50 IP55 6 cable ends M25 650°C junction box

Gewiss GW44004 100x100x50 IP55 6 cable ends M25 650°C junction box

Price on request

€4.49

€0

Into a basketIn the basketGo
