Gewiss GW44696 4-pin 1x6-35qmm and 1x4-25qmm 5x1.5-10qmm terminal block

In stock

SKU: 660609

Price on request

€41.43

€0

Overview

Terminal strips and terminal blocks

Property	Value
Number of poles:	4
Color:	gray
Rated voltage:	750 V
Material of the insulating body:	Thermoplastic
Rated current In:	100 A
Connectable conductor cross-section single-wire:	35 to 1.5 mm²
Connectable Stranded conductor cross-section:	35 to 1.5 mm²
Connectable stranded conductor cross-section with wire end ferrule:	25 to 1.5 mm²
Mounting type:	DIN rail TH35
Design of electrical connection 1:	Screw connection
Design of electrical connection 2:	Screw connection
Number of terminal points per pole:	7
End plate required:	yes
Explosion-tested version 'Ex e':	no
Transparent:	yes
