ABB Stotz-Kontakt 1SCA105078R1001 OT60F3C 3-pl.60A without handle and shaft load changeover switch

ABB Stotz-Kontakt 1SCA105078R1001 OT60F3C 3-pl.60A without handle and shaft load changeover switch

In stock

SKU: 817818

Price on request

€253.99

€0

Overview

The manually operated switch disconnectors of the OT series are unique in their variety and flexibility. The OT series switches currents from 16 A to 4000 A and at voltages of up to 690 V AC. Despite their high performance, the switches are very easy to operate and take up little space. The freely selectable installation position enables a high level of flexibility and efficiency in planning. The OT switch disconnectors can be used as main switches in the main or sub-distribution board. ABB also offers a wide range of accessories for this series, such as extension shafts, handles and terminal covers. This means that OT switch disconnectors can also be used in the most demanding applications.

Property	Value
Number of poles:	3
Rated continuous current Iu:	60 A
Max. Rated operating voltage Ue at AC:	750 V
Version as EMERGENCY STOP device:	no
Protection class (IP), front:	IP20
Device design:	Built-in device, plug-in technology
Design of the actuating element:	without
Suitable for floor mounting:	no
Integrated motor drive:	no
Suitable for front mounting 4-hole:	yes
Version as maintenance/repair switch:	yes
Voltage release optional:	no
Suitable for front mounting central:	no
Suitable for intermediate installation:	no
Suitable for distribution board installation:	yes
Version as main switch:	yes
Version as safety switch:	no
Motor drive optional:	no
Lockable:	yes
Version as reversing switch:	no
Rated short-time withstand current Icw:	1 kA
Color of the actuating element:	black
Rated operating voltage:	750 V
Rated continuous current at AC-21, 400 V:	63 A
Number of switches:	1
Rated continuous current at AC-23, 400 V:	45 A
Protection class (NEMA):	1
