ABB Stotz-Kontakt 1SCA126180R1001 OTDC100U22 4-pole 100A switch disconnector

In stock
SKU: 1031893
€809.30
Into a basketIn the basketGo

Overview

The manually operated switch disconnectors of the OTDC series are a cost-effective and reliable solution for a wide range of industrial DC applications. The OTDC series switches currents from 100 A to 800 A (IEC) and from 100 A to 400 A (UL) at voltages up to 1500 V DC. Due to different mounting options, the switches enable a high level of flexibility and efficiency in planning. The series has UL and IEC approvals. The UL variant is only available as a side-operated version. In addition, the switches are designed to be used in particularly high ambient temperatures. In addition, the power loss has been reduced by 50%. ABB offers you a wide range of accessories for these switches, such as extension shafts, handles, auxiliary switches and terminal covers. The DC switch disconnectors can therefore be used in the most demanding applications.

PropertyValue
Width:185.4 mm
Number of poles:4
Weight:2.2
Weight unit:KG
Statistical commodity number:85365080
Rated continuous current Iu:160 A
Protection class (IP), front:IP20
Connection type main circuit:Bolt connection
Version as main switch:yes
Version as maintenance/repair switch:yes
Suitable for front mounting 4-hole:yes
Suitable for distribution board installation:yes
Device design:Built-in device, fixed installation technology
Rated operating voltage:1000 V
Number of switches:1
Protection class (NEMA):1
Brief description:OTDC100U22 DC load disconnector 4-pole 100A without handle and shaft/UL
Height:262 mm
Depth:90.5 mm
Design of the actuating element:other

Characteristics

HABOTDC100U22 4-pole 100A
ManufacturerABB Stotz-Kontakt
HAN1SCA126180R1001
GTIN6417019561608
Connection type main circuitBolt connection
Number of switches1
Designed as main switchYes
Designed as a maintenance/repair switchYes
Design of the actuating elementOther
Rated operating voltage1000V
Rated continuous current Iu160A
Width185.4 mm
Suitable for front mounting 4-holeYes
Suitable for distribution board installationYes
Device typeBuilt-in device Fixed installation technology
Weight2,2
Weight unit kg
Height262 mm
Short descriptionOTDC100U22 DC load break switch 4-pole 100A without handle and shaft/UL
Number of poles4
Protection class (IP), frontIP20
Protection class (NEMA)1
Statistical commodity code85365080
Depth90.5 mm
ABB Stotz-Kontakt 1SCA126180R1001 OTDC100U22 4-pole 100A switch disconnector
ABB Stotz-Kontakt 1SCA126180R1001 OTDC100U22 4-pole 100A switch disconnector
€809.30
