ABB Stotz-Kontakt 1SDA107705R0001 XT4V 160 MA 32 Im=160...320 3p FF MA circuit breaker

ABB Stotz-Kontakt 1SDA107705R0001 XT4V 160 MA 32 Im=160...320 3p FF MA circuit breaker

In stock

SKU: 781759

Price on request

€999.41

€0

Overview

Molded case circuit breakers for system protection in accordance with EN 60947-2 (DIN0660, Part 101), molded case load disconnectors in accordance with EN 60947-3 (DIN0660, Part 107). The Tmax XT molded case/load disconnectors meet the different system requirements of direct and alternating current networks. Tmax XT with thermomagnetic or electronic releases can be used to protect power distribution systems, cables, generators, motors and reinforced neutral conductors. Many of these circuit breakers can also be used in communication systems or 400Hz systems. Extensive connection conversion kits, mechanical and electrical accessories as well as version conversion kits (plug-in/withdrawable) are available.

Property	Value
Rated continuous current Iu:	160 A
Connection type main circuit:	Bolt connection
Number of poles:	3
Device design:	Built-in device, fixed installation technology
Position of connection for main circuit:	front
Protection class (IP):	IP20
Setting range of the instantaneous short-circuit release:	160 to 320 A
Rated voltage:	690 V
Rated short-circuit breaking current Icu at 400 V, 50 Hz:	150 kA
Suitable for DIN rail mounting:	no
Design of the actuating element:	toggle
With undervoltage release:	no
Integrated earth fault protection:	no
Motor drive integrated:	no
Motor drive optional:	yes
With trip detector:	no
Complete device with protection unit:	yes
DIN rail mounting optional:	yes
