ABB Stotz-Kontakt BCM/S16.2.0.1 , BAC module, 16 digital inputs, 100-240 V , 2CDG120063R0011

In stock

SKU: 473562

Price on request

€268.26

€0

Overview

Expansion module for the BAC/S building automation controller KNX with 16 digital inputs for 100 - 240 V AC. Connection of the cables via plug-in spring terminals.

Property	Value
Number of digital inputs:	16
Redundancy capability:	no
Design of the electrical connection:	clamp connection
Supply voltage for DC:	24 V
Height:	135 mm
Width:	34 mm
Depth:	74 mm
Type of supply voltage:	DC
Type of input voltage:	AC
Permissible voltage at Input:	0 to 264 V
Suitable for safety functions:	no
Input current for signal 1:	8 mA
Delay time for signal change:	24 ms
Short-circuit protection, outputs available:	no
Associated equipment (Ex ia):	no
Associated equipment (Ex ib):	no
Digital outputs configurable:	no
Digital inputs configurable:	yes
