ABB Stotz-Kontakt E480/3KB, disconnector 3P, 80A, switch handle black, 2CCE180300R0141

In stock

SKU: 197742

Price on request

€86.91

€0

Overview

As a main switch between the last overcurrent protection device before the measuring device and the circuit distributor. The main switches can also be used for various other applications. With double-breaking switching contacts.

Property	Value
Number of poles:	3
Rated current:	80 A
Rated voltage:	400 V
Width in modular spacing:	2.5
Switching function:	Off switch
With signal lamp:	no
Type of voltage:	AC
Color of the cap:	gray
Protection class (IP):	IP20
Min. Rated voltage:	24 V
Short-circuit strength (Icw):	10 kA
Forced disconnection (according to DIN VDE 0113):	yes
Installation depth:	70 mm
Number of contacts as normally open:	3
