Rated operating current Ie at DC-13, 230 V0.4 A
Rated operating current Ie at DC-13, 125 V0.6 A
Rated operating current Ie at AC-15, 24 V10 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V5.5 A
HABLS32P52B11
HAN1SBV010352R1211
GTIN3471522614865
Number of contacts as normally open1
Number of contacts as opener1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementTappet
Design of the electrical connectionCable entry (metric)
Alignment of the actuatorOther
Rated operating current Ie at AC-15, 230 V3.1 A
Rated operating current Ie at DC-13, 24 V6A
Housing coatingOther
Width of the sensor50 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height of the sensor126.5 mm
Length of the sensor52 mm
With status displayNo
Switching functionSnap action contact
Switching function latchingNo
IP protection)IP65
Protection class (NEMA)4
Ambient temperature during operation-25 to 70 °C
Housing materialPlastic
Forced openingNo
