Rated operating current Ie at DC-13, 230 V0.4 A
Rated operating current Ie at DC-13, 125 V0.6 A
Rated operating current Ie at AC-15, 24 V10 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V5.5 A
HABLS35M71B11
HAN1SBV013771R1211
GTIN3471522624826
Number of contacts as normally open1
Number of contacts as opener1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementTappet
Design of the electrical connectionConnector 1/2 inch
Alignment of the actuatorOther
Rated operating current Ie at AC-15, 230 V3.1 A
Rated operating current Ie at DC-13, 24 V6A
Housing coatingPowder coated
Width of the sensor30 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsNo
Housing designCuboid
Height of the sensor170 mm
Length of the sensor42 mm
With status displayNo
Switching functionSnap action contact
Switching function latchingNo
IP protection)IP66
Protection class (NEMA)4X
Ambient temperature during operation-25 to 70 °C
Housing materialMetal
Forced openingNo
