ABB Stotz-Kontakt S203-D20NA D20A 3-pole+NA 6kA circuit breaker, 2CDS253103R0201

The circuit breakers of the S 200 series protect cables and lines against overload and short circuits in accordance with DIN0100-430 and DIN0100-530. They comply with the construction regulations DIN0641-11 or IEC/EN 60898-1, DIN0660-101 or IEC/EN60947-2 and UL1077. Their patented connection terminal ensures simple and safe contacting and handling using a pressure plate. For better visibility when wiring, the connection opening for cables is located above the connection opening for the phase busbar. Conductor cross-sections of up to 35 mm² can be connected directly to the device via the connection terminal with insulation in protection class IP20. The extensive range of accessories offers you everything you need for your installation tasks. Numerous approvals make the S 200 fit for worldwide use. Each device is subjected to three intensive tests for quality and performance before delivery.
