ABB Stotz-Kontakt Sense7Z Key SS, Sense7Z replacement actuator made of stainless steel, 2TLA050040R0212

ABB Stotz-Kontakt Sense7Z Key SS, Sense7Z replacement actuator made of stainless steel, 2TLA050040R0212

In stock

SKU: 462729

Price on request

€86.26

€0

Overview

Sense7 are contactless, electronic locking devices with coding according to type 4 with a low coding level according to EN ISO 14119. The magnetic switches are fully electronic without reed contacts. There are versions made of plastic and stainless steel, each with different cable lengths.

Property	Value
Category according to EN 954-1:	4
Suitable for safety functions:	yes
Length of the sensor:	14 mm
Height of the sensor:	25 mm
Type of actuation:	Magnet
Width of the sensor:	88 mm
Performance level according to EN ISO 13849-1:	Level e
Protection class (IP):	IP67
Design of the electrical Connection:	other
Design of the switching output:	other
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Housing design:	special design
Housing coating:	uncoated
Secured switching distance OFF:	10 mm
Secured switching distance ON:	20 mm
Ambient temperature:	-25 to 105 °C
Mechanical installation condition for sensor:	not flush
Cross-circuit/short-circuit detection possible:	yes
Switching distance:	5 mm
With monitoring function for downstream devices:	no
Housing material:	stainless steel
SIL according to IEC 61508:	3
With status display:	no
Protection class (NEMA):	other
