ABB Striebel & John KS4230 measuring and transformer cabinet TwinLine, surface-mounted, 2CPX032953R9999

In stock
SKU: 448481
€5,760.01
Into a basketIn the basketGo

Overview

The measuring and converter cabinets of the TwinLine series are designed for surface mounting. The distributors are used indoors in, for example, functional and industrial buildings. The housings are delivered with a door and have top, bottom and side cable entry options. One advantage is the wide door opening angle of 180°. In addition, the doors can be easily removed if required. Applicable standards: DIN EN 61439-10660-600-1, color white RAL 7035 and powder-coated.

PropertyValue
Number of fields:3
Height:1850 mm
Width:800 mm
Depth:350 mm
Protection class (IP):IP54
Design:eHZ
Lower connection compartment:with busbar
Material:Sheet steel
With mounting plate:no
Mounting type:Surface-mounted
Installation width:800 mm
Installation height:1850 mm
Installation depth:350 mm

Characteristics

Number of fields3
HABKS4230 complete TW312S
HAN2CPX032953R9999
GTIN4011617329534
VersionEHZ
Width800 mm
Installation width800 mm
Installation height1850 mm
Installation depth350 mm
Height1850 mm
With mounting plateNo
Mounting typeSurface-mounted
IP protection)IP54
Depth350 mm
Lower connection compartmentWith busbar
MaterialSheet steel
