Flat module for control units, from housing depth 160 mm. Width 500 mm. Height 300 mm. NT profile yes. ST profile yes. PLE 48. PU 1. Module kits for control units. Module kit in flat or deep design for control units. With lowered device support rail 35 x 15 mm and closed cover. Installation dimensions 97 mm (MF..), 104 mm (MT..). .
| Property | Value |
| Height: | 300 mm |
| Width: | 500 mm |
| Depth: | 125 mm |
| Number of DIN rails: | 2 |
| Number of pitch units per DIN rail: | 24 |
| With N-PE terminals: | no |
| With cover: | yes |
| Type of cover: | closed |
| With mounting plate: | no |
