HAN1808-3FW090
GTIN4260712970688
Covering the luminaire with thermal insulation material possibleNo
Rated lifetime L80/B10 at 25 °C50000 hours
Rated luminous flux according to IEC 62722-2-13420lm
Rated ambient temperature according to IEC62722-2-1-10 to 40 °C
Suitable for computer workstations according to EN 12464-1Yes
Width620 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearYes
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature4000K
Color rendering index CRI90-100
Suitable for surface mountingNo
Suitable for ceiling mountingNo
Suitable for flush mountingNo
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingNo
Housing colorAluminum
Height/Depth14 mm
Luminaire with limited surface temperature D-markNo
LampsLED not replaceable
Light colorWhite
Length620 mm
Max. system performance38W
With operating deviceNo
With motion detectorNo
With light sourceNo
With light sensorNo
With air slotsNo
Without dimming functionNo
Impact resistanceIK02
IP protection)IP20
Protection classIII
Voltage typeDC
Cover materialPlastic opal
Housing materialAluminum
