HAN3304-0FW120
GTIN4260523599405
Suspension includedNo
Execution of the gridWithout
Rated lifetime L80/B10 at 25 °C50000 hours
Rated luminous flux according to IEC 62722-2-15670lm
Operating deviceLED control gear current controlled
Suitable for computer workstations according to EN 12464-1Yes
Width300 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Direct/indirect components can be controlled separatelyNo
Color temperature4000K
Color rendering index CRI80-89
VersionWithout
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Housing colorWhite
Glow wire test according to IEC 60695-2-11Without
Height/Depth23 mm
Power factor0.97
Luminaire with limited surface temperature D-markNo
LampsLED not replaceable
Light emissionDirect/indirect
Light colorWhite
Light distributorWithout
Length1200 mm
Max. system performance54W
With operating deviceYes
With light sourceNo
Nominal voltage220 to 240 V
Without dimming functionNo
ReflectorWithout
IP protection)IP40
Protection classII
Voltage typeAC
Housing materialAluminum
