Eaton 026777 KT21 cable grommet

In stock

SKU: 512328

Price on request

€1.04

€0

Overview

Cable grommets, suitable for wall thickness 2-8mm, soft PVC, cadmium and lead free, cable entry PG 21, bore diameter=29.5mm, cable outer diameter=12.5-20mm, use cable NYM/NYY, 4-core=1.5-16qmm, similar to RAL 7035,

Property	Value
For wall thickness:	1 to 6.5 mm
Design:	closed
Suitable for cable diameters:	12.5 to 20 mm
Angle design:	no
With strain relief:	no
Bore diameter:	29.5 mm
Color:	gray
Material:	plastic
Halogen-free:	no
Fireproof:	no
Gas-tight:	yes
Total length:	20 mm
Surface:	other
Shrink technology:	no
Protection class (IP):	IP65
Waterproof:	yes
Material quality:	Polyvinyl chloride (PVC)
Insert for cable gland:	no
Cable entry:	round
Number of Cable:	1
Thread size PG:	21
Operating temperature:	-5 to 40 °C
