Eaton AZ-3-C100 C100A 3-pole high-performance circuit breaker, 211806

Eaton AZ-3-C100 C100A 3-pole high-performance circuit breaker, 211806

In stock

SKU: 475515

Price on request

€345.22

€0

Into a basketIn the basketGo

Overview

AZ circuit breaker, 3-pole, tripping characteristic: C, rated current In: 100 A, switching devices for industrial applications and high-end commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	100 A
Rated voltage:	400 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	4.5
Number of poles (total):	3
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	75 mm
Protection class (IP):	IP20
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	20 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	20 kA
Pollution degree:	2
Switching neutral conductor:	no
Number of protected poles:	3
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 55 °C
Connectable conductor cross-section, stranded:	2.5 to 50 mm²
Connectable conductor cross-section, solid:	2.5 to 50 mm²

Characteristics

HABAZ-3-C100 C100A 3-pin

Manufacturer

HAN211806

GTIN4015082118068

Connectable conductor cross-section solid2.5 to 50 mm²

Connectable conductor cross-section stranded2.5 to 50 mm²

Number of protected poles3

Trigger characteristicsC

Rated insulation voltage Ui440V

Rated switching capacity Icu according to IEC 60947-2 at 230 V20kA

Rated switching capacity Icu according to IEC 60947-2 at 400 V20kA

Rated voltage400V

Rated impulse withstand voltage Uimp4kV

Rated current100A

Width in pitch units4.5

Installation depth75 mm

Energy limitation class3

Frequency50 to 60 Hz

Switching neutral conductorNo

Number of poles (total)3

IP protection)IP20

Voltage typeAC

Ambient temperature during operation-25 to 55 °C

Degree of contamination2

Additional equipment possibleYes

Overvoltage category3
