Eaton AZ-4-C25 C25A 4-pole high-performance circuit breaker, 211777

Eaton AZ-4-C25 C25A 4-pole high-performance circuit breaker, 211777

In stock

SKU: 476620

Price on request

€219.36

€0

Into a basketIn the basketGo

Overview

Circuit breaker AZ, 4-pole, tripping characteristic: C, rated current In: 25 A, switching devices for industrial applications and high-end commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	25 A
Rated voltage:	400 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	6
Number of poles (total):	4
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	75 mm
Protection class (IP):	IP20
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	25 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	25 kA
Pollution degree:	2
Switching neutral conductor:	yes
Number of protected poles:	4
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 55 °C
Connectable conductor cross-section, stranded:	2.5 to 50 mm²
Connectable conductor cross-section, solid:	2.5 to 50 mm²

Characteristics

HABAZ-4-C25 C25A 4-pin

Manufacturer

HAN211777

GTIN4015082117771

Connectable conductor cross-section solid2.5 to 50 mm²

Connectable conductor cross-section stranded2.5 to 50 mm²

Number of protected poles4

Trigger characteristicsC

Rated insulation voltage Ui440V

Rated switching capacity Icu according to IEC 60947-2 at 230 V25kA

Rated switching capacity Icu according to IEC 60947-2 at 400 V25kA

Rated voltage400V

Rated impulse withstand voltage Uimp4kV

Rated current25A

Width in pitch units6

Installation depth75 mm

Energy limitation class3

Frequency50 to 60 Hz

Switching neutral conductorYes

Number of poles (total)4

IP protection)IP20

Voltage typeAC

Ambient temperature during operation-25 to 55 °C

Degree of contamination2

Additional equipment possibleYes

Overvoltage category3
