Eaton AZ-4-C32 C32A 4-pole high-performance circuit breaker, 211782

Eaton AZ-4-C32 C32A 4-pole high-performance circuit breaker, 211782

In stock

SKU: 476621

Price on request

€244.19

€0

Into a basketIn the basketGo

Overview

Circuit breaker AZ, 4-pole, tripping characteristic: C, rated current In: 32 A, switching devices for industrial applications and high-end commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	32 A
Rated voltage:	400 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	6
Number of poles (total):	4
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	75 mm
Protection class (IP):	IP20
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	25 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	25 kA
Pollution degree:	2
Switching neutral conductor:	yes
Number of protected poles:	4
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 55 °C
Connectable conductor cross-section, stranded:	2.5 to 50 mm²
Connectable conductor cross-section, solid:	2.5 to 50 mm²

Characteristics

HABAZ-4-C32 C32A 4-pin

Manufacturer

HAN211782

GTIN4015082117825

Connectable conductor cross-section solid2.5 to 50 mm²

Connectable conductor cross-section stranded2.5 to 50 mm²

Number of protected poles4

Trigger characteristicsC

Rated insulation voltage Ui440V

Rated switching capacity Icu according to IEC 60947-2 at 230 V25kA

Rated switching capacity Icu according to IEC 60947-2 at 400 V25kA

Rated voltage400V

Rated impulse withstand voltage Uimp4kV

Rated current32 A

Width in pitch units6

Installation depth75 mm

Energy limitation class3

Frequency50 to 60 Hz

Switching neutral conductorYes

Number of poles (total)4

IP protection)IP20

Voltage typeAC

Ambient temperature during operation-25 to 55 °C

Degree of contamination2

Additional equipment possibleYes

Overvoltage category3
