Eaton CI43-S60-400/3-1XNH00 HS 400A 3-pole distribution housing, 194584

In stock
SKU: 479903
€313.24
Into a basketIn the basketGo

Overview

NH distribution housing with transparent cover, 1x switching device NH00 on busbar system 400A, 3-pole, carrier included for N+PE for retrofitting, with CU rails L1/L2/L3: 20 x 10 mm, N: without, PE: without, without terminals

PropertyValue
Housing height:375 mm
Rated operating current Ie:130 A
Size of the fuse links:NH00
Rated insulation voltage Ui:800 V
Degree of protection (IP):IP65
Equipment of the fuse switch housing:with fuse switch disconnector
Number of poles:3
With fuse monitoring:no
Max. Rated operating voltage Ue at AC:690 V
Protection class (NEMA):other

Characteristics

Rated operating current Ie130 A
HABCI43-S60-400/3-1XNH00 HS 400A 3-pole
ManufacturerEaton
HAN194584
GTIN9010238058866
Rated insulation voltage Ui800V
Max. rated operating voltage Ue at AC690V
With fuse monitoringNo
Number of poles3
IP protection)IP65
Protection class (NEMA)Other
