Eaton E55BLT1F clamp AC quad.40 plastic sensor, 135815

Eaton E55BLT1F clamp AC quad.40 plastic sensor, 135815

In stock

SKU: 474355

Price on request

€120.12

€0

Overview

Proximity switch, inductive sensors, range: E55 limit switch style series, connection: 2-wire, design (external dimensions): 50 x 50 x 128 mm, rated operating voltage: Ue= 35 - 250 V AC, rated switching distance: Sn= 40 mm, installation type: non-flush, screw terminal, contacts P = normally closed/normally open programmable: 1 P, material: plastic, protection class: IP67, standards and regulations: IEC/EN 60947-5-2

Property	Value
Switching distance:	40 mm
Voltage type:	AC
Mechanical installation condition for sensor:	not flush
Width of sensor:	50 mm
Rated control supply voltage Us at AC 50 Hz:	35 to 250 V
Height of sensor:	50 mm
Performance level according to EN ISO 13849-1:	without
Rated control supply voltage Us at AC 60 Hz:	35 to 250 V
Design of the interface:	without
Design of the switching function:	programmable/configurable
Type of actuation:	metallic target
Switching frequency:	25 Hz
Length of the sensor:	128 mm
Pressure-resistant:	no
Suitable for safety functions:	no
Number of semiconductor outputs with signaling function:	1
Design of the interface for safety-related communication:	without
Design of the electrical Connection:	terminal
Explosion protection category for gas:	without
Explosion protection category for dust:	without
Housing design:	cuboid
Housing coating:	other
Cascadable:	no
Supply voltage:	35 to 250 V
With monitoring function for downstream devices:	no
Housing material:	plastic
SIL according to IEC 61508:	without
