Eaton FAZ-B20/1N miniature circuit breaker, 278649

Eaton FAZ-B20/1N miniature circuit breaker, 278649

In stock

SKU: 474962

Price on request

€43.01

€0

Into a basketIn the basketGo

Overview

Circuit breaker FAZ, 1-pole+N, tripping characteristic: B, rated current In: 20 A, switching devices for industrial applications and high-end commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	20 A
Rated voltage:	230 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	4
Number of poles (total):	4
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	70.5 mm
Protection class (IP):	IP20
Rated switching capacity Icn according to EN 60898 at 230 V:	6 kA
Rated switching capacity Icn according to EN 60898 at 400 V:	6 kA
Pollution level:	2
Switching neutral conductor:	yes
Number of protected poles:	4
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 75 °C
Connectable conductor cross-section, stranded:	1 to 25 mm²
Connectable conductor cross-section, solid:	1 to 25 mm²

Characteristics

HABFAZ-B20/1N

Manufacturer

HAN278649

GTIN4015082786496

Connectable conductor cross-section solid1 to 25 mm²

Connectable conductor cross-section stranded1 to 25 mm²

Number of protected poles4

Trigger characteristicsC

Rated insulation voltage Ui440V

Rated switching capacity Icn according to EN 60898 at 230 V6kA

Rated switching capacity Icn according to EN 60898 at 400 V6kA

Rated voltage230V

Rated impulse withstand voltage Uimp4kV

Rated current20A

Width in pitch units4

Installation depth70.5 mm

Energy limitation class3

Frequency50 to 60 Hz

Switching neutral conductorYes

Number of poles (total)4

IP protection)IP20

Voltage typeAC

Ambient temperature during operation-25 to 75 °C

Degree of contamination2

Additional equipment possibleYes

Overvoltage category3
