Eaton FAZ-B4/2 4A 2-pole circuit breaker, 278726

In stock
SKU: 474833
€68.62
Into a basketIn the basketGo

Overview

High-quality residual current circuit breaker/circuit breaker combination independent of mains voltage, contact position indicator red-green, clamping aid - rear plug protection, tri-stable locking slide - enables removal from an existing busbar assembly, extensive range of accessories can be retrofitted, large selection of rated residual currents, rated currents up to 40A, tripping characteristics B, C, D, rated switching capacity 10kA, suitable for use outdoors (construction site power and outdoor distributors) down to -25°C

PropertyValue
Tripping characteristic:B
Rated current:4 A
Rated voltage:400 V
Type of voltage:AC
Frequency:50 to 60 Hz
Width in pitch units:2
Number of poles (total):2
Energy limitation class:3
Additional equipment possible:yes
Overvoltage category:3
Installation depth:70.5 mm
Protection class (IP):IP20
Rated switching capacity Icn according to EN 60898 at 230 V:10 kA
Rated switching capacity Icu according to IEC 60947-2 at 230 V:15 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:15 kA
Rated switching capacity Icn according to EN 60898 at 400 V:10 kA
Pollution level:2
Switching neutral conductor:no
Number of protected poles:2
Rated insulation voltage Ui:440 V
Rated impulse withstand voltage Uimp:4 kV
Ambient temperature during operation:-25 to 75 °C
Connectable conductor cross-section, stranded:1 to 25 mm²
Connectable conductor cross-section, solid:1 to 25 mm²

Characteristics

HABFAZ-B4/2 4A 2-pole
ManufacturerEaton
HAN278726
GTIN4015082787264
Connectable conductor cross-section solid1 to 25 mm²
Connectable conductor cross-section stranded1 to 25 mm²
Number of protected poles2
Trigger characteristicsB
Rated insulation voltage Ui440V
Rated switching capacity Icn according to EN 60898 at 230 V10kA
Rated switching capacity Icn according to EN 60898 at 400 V10kA
Rated switching capacity Icu according to IEC 60947-2 at 230 V15kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V15kA
Rated voltage400V
Rated impulse withstand voltage Uimp4kV
Rated current4 A
Width in pitch units2
Installation depth70.5 mm
Energy limitation class3
Frequency50 to 60 Hz
Switching neutral conductorNo
Number of poles (total)2
IP protection)IP20
Voltage typeAC
Ambient temperature during operation-25 to 75 °C
Degree of contamination2
Additional equipment possibleYes
Overvoltage category3
