Eaton FAZ-C3/1-NA-DC 3A 1-pole circuit breaker, 113753

Eaton FAZ-C3/1-NA-DC 3A 1-pole circuit breaker, 113753

In stock

SKU: 480013

Price on request

€109.97

€0

Into a basketIn the basketGo

Overview

Circuit breaker FAZ-DC, 1-pole, tripping characteristic: C, rated current In: 3 A, switching devices for export to North America (UL validated)

Property	Value
Tripping characteristic:	C
Rated current:	3 A
Rated voltage:	250 V
Type of voltage:	DC
Frequency:	50 to 60 Hz
Width in pitch units:	1
Number of poles (total):	1
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	70.5 mm
Protection class (IP):	IP20
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	10 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	10 kA
Pollution degree:	2
Switching neutral conductor:	no
Number of protected poles:	1
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 75 °C
Connectable conductor cross-section, stranded:	1 to 25 mm²
Connectable conductor cross-section, solid:	1 to 25 mm²

Characteristics

HABFAZ-C3/1-NA-DC 3A 1-pole

Minimal order2 pieces

Manufacturer

HAN113753

GTIN4015081131389

Connectable conductor cross-section solid1 to 25 mm²

Connectable conductor cross-section stranded1 to 25 mm²

Number of protected poles1

Trigger characteristicsC

Rated insulation voltage Ui440V

Rated switching capacity Icu according to IEC 60947-2 at 230 V10kA

Rated switching capacity Icu according to IEC 60947-2 at 400 V10kA

Rated voltage250V

Rated impulse withstand voltage Uimp4kV

Rated current3 A

Width in pitch units1

Installation depth70.5 mm

Energy limitation class3

Frequency50 to 60 Hz

Switching neutral conductorNo

Number of poles (total)1

IP protection)IP20

Voltage typeDC

Ambient temperature during operation-25 to 75 °C

Degree of contamination2

Additional equipment possibleYes

Overvoltage category3
