Eaton FRCDM-63/4/03-S/B 63/0.3A 4-pole residual current circuit breaker, all-current sensitive, 167902

In stock
SKU: 478655
€1,212.48
Into a basketIn the basketGo

Overview

Residual current circuit breaker FRCdM, 4-pole, rated current In: 63 A, rated short-circuit strength Icn: 10 with backup fuse kA, rated residual current IN: 0.3 A, switching devices for industrial applications and high-end commercial buildings

PropertyValue
Rated voltage:415 V
Rated current:63 A
Rated residual current:0.3 mA
Mounting type:DIN rail
Protection class (IP):IP20
Frequency:50 Hz
Number of poles:4
Width in pitch units:4
Selective type:yes
Residual current type:B
Additional equipment possible:yes
Installation depth:70.5 mm
Short-circuit strength (Icw):10 kA
Surge current strength:5 kA
Short-time delayed type:no
Rated insulation voltage Ui:440 V
Rated impulse withstand voltage Uimp:4 kV
With locking device:yes
Ambient temperature during Operating:-25 to 60 °C
Pollution level:2
Connectable conductor cross-section, stranded:1.5 to 16 mm²
Connectable conductor cross-section, single-wire:1.5 to 35 mm²

Characteristics

HABFRCDM-63/4/03-S/B 63/0.3A 4-pin
ManufacturerEaton
HAN167902
GTIN4015081644773
Connectable conductor cross-section solid1.5 to 35 mm²
Connectable conductor cross-section stranded1.5 to 16 mm²
Rated residual current0.3mA
Rated insulation voltage Ui440V
Rated voltage415V
Rated impulse withstand voltage Uimp4kV
Rated current63 A
Width in pitch units4
Installation depth70.5 mm
Residual current typeB
Frequency50Hz
Short circuit strength (Icw)10kA
Short-time delayed typeNo
With locking deviceYes
Mounting typeDIN rail
Number of poles4
IP protection)IP20
Selective typeYes
Surge current strength5kA
Ambient temperature during operation-25 to 60 °C
Degree of contamination2
Additional equipment possibleYes
