Eaton mRB6-10/3N/C/003-A combination switch, 120658

Eaton mRB6-10/3N/C/003-A combination switch, 120658

In stock

SKU: 475723

Price on request

€331.58

€0

Overview

FI/LS combination switch mRB6, 3-pole+N, rated current In: 10 A, rated residual current IN: 0.03 A, rated switching capacity according to IEC/EN 60947-2: 6 kA, rated switching capacity according to IEC/EN 61009: 6 kA, switching devices for residential and commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	10 A
Rated residual current:	0.03 A
Rated voltage:	400 V
Frequency:	50 Hz
Number of poles (total):	4
Width in pitch units:	4
Residual current type:	A
Installation depth:	70 mm
Surge current strength:	0.25 kA
Protection class (IP):	IP20
Energy limitation class:	3
Overvoltage category:	3
Pollution degree:	2
Switching neutral conductor:	yes
Number of protected poles:	4
Voltage type:	AC
False tripping protection:	no
Rated insulation voltage Ui:	500 V
Rated impulse withstand voltage Uimp:	4 kV
Rated breaking capacity according to EN 61009:	6 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1:	6 kA
Shutdown characteristics:	instantaneous
With locking device:	no
Ambient temperature during operation:	-25 to 40 °C
Connectable conductor cross-section, single-wire:	1 to 25 mm²
Connectable conductor cross-section, stranded:	1 to 25 mm²
