Eaton PKZM01-20 motor protection switch, 3-pole, Ir = 16 - 20 A, 283383

Eaton PKZM01-20 motor protection switch, 3-pole, Ir = 16 - 20 A, 283383

In stock

SKU: 224915

Price on request

€83.47

€0

Overview

Motor protection switch according to IEC/EN60947, 3-pole, size PKZM01, with adjustable overload and instantaneous short-circuit release, phase failure sensitive, screw and snap-on mounting, cap installation dimension 45mm, rated operating voltage Ue 690V, protection class IP20, finger-safe according to 0106 T. 100, available accessories: auxiliary switch, voltage release

Property	Value
Number of poles:	3
Rated operating voltage:	690 V
Rated operating power at AC-3, 230 V:	5.5 kW
Rated operating power at AC-3, 400 V:	9 kW
Rated continuous current Iu:	20 A
Rated ultimate short-circuit breaking current Icu at 400 V, AC:	50 kA
Overload release current setting:	16 to 20 A
Triggering technology:	thermomagnetic
Phase failure sensitive:	yes
Connection type main circuit:	screw connection
Device design:	Built-in device, fixed installation technology
Protection class (IP):	IP20
Width:	45 mm
Setting range of the instantaneous short-circuit release:	310 A
With integrated auxiliary switch:	no
With integrated undervoltage release:	no
Height:	90 mm
Depth:	93 mm
Design of the actuating element:	Push button
With thermal protection:	no
