Eaton PLHT-C63/4 circuit breaker, 63A, 4p, C-Char , 248090

Eaton PLHT-C63/4 circuit breaker, 63A, 4p, C-Char , 248090

In stock

SKU: 218133

Price on request

€468.45

€0

Overview

Miniature circuit breaker PLHT, 4-pole, tripping characteristic: C, rated current In: 63 A, rated switching capacity according to IEC/EN 60898-1:, switching devices for industrial applications and high-end commercial buildings

Property	Value
Tripping characteristic:	C
Rated current:	63 A
Rated voltage:	400 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	6
Number of poles (total):	4
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	75 mm
Protection class (IP):	IP20
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	25 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	25 kA
Pollution degree:	2
Switching neutral conductor:	yes
Number of protected poles:	4
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 55 °C
Connectable conductor cross-section, stranded:	2.5 to 50 mm²
Connectable conductor cross-section, solid:	2.5 to 50 mm²
