Eaton PLI-D8/1N miniature circuit breaker, 8A, 1p+N, D-Char, 101283

Eaton PLI-D8/1N miniature circuit breaker, 8A, 1p+N, D-Char, 101283

In stock

SKU: 218329

Price on request

€47.55

€0

Overview

Miniature circuit breaker, PLI, 1-pole+N, tripping characteristic: D, rated current In: 8 A, rated switching capacity according to IEC/EN 60898-1: 10 kA, switching devices for residential and commercial buildings

Property	Value
Tripping characteristic:	D
Rated current:	8 A
Rated voltage:	230 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	2
Number of poles (total):	2
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	70.5 mm
Protection class (IP):	IP20
Rated switching capacity Icn according to EN 60898 at 230 V:	10 kA
Rated switching capacity Icn according to EN 60898 at 400 V:	10 kA
Pollution level:	2
Switching neutral conductor:	yes
Number of protected poles:	1
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 75 °C
Connectable conductor cross-section, stranded:	1 to 25 mm²
Connectable conductor cross-section, solid:	1 to 25 mm²
