HABZSD-TRN/MON/PL
HAN255803
GTIN4015082558031
Connection type main circuitFrame clamp
Designed as main switchYes
Designed as an EMERGENCY STOP deviceNo
Designed as a safety switchYes
Design of the actuating elementRocker arm
Conditional rated short-circuit current Iq100kA
Rated continuous current Iu160A
Suitable for floor mountingYes
Suitable for front mountingNo
Suitable for busbar constructionNo
Suitable for fuse insertsNH00
Max. rated operating voltage Ue at AC500V
With fuse monitoringYes
Equipped with connectorsNo
Motor drive integratedNo
Motor drive optionalNo
Number of poles1
Position of the actuatorIn front
Protection class (IP), frontIP40
