HABZSD-TRN
HAN226435
GTIN4015082264352
Connection type main circuitRail connection
Number of switches1
Designed as main switchYes
Designed as an EMERGENCY STOP deviceNo
Designed as a safety switchNo
Designed as a maintenance/repair switchYes
Version as reversing switchNo
Design of the actuating elementRocker arm
Rated continuous current Iu160A
Rated continuous current at AC-21, 400 V160A
Rated continuous current at AC-23, 400 V160A
Color of the actuatorGray
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Suitable for front mounting CentralNo
Suitable for distribution board installationYes
Suitable for intermediate constructionNo
Device typeBuilt-in device Fixed installation technology
Motor drive integratedNo
Motor drive optionalNo
Number of poles1
Protection class (IP), frontIP40
Protection class (NEMA)Other
Voltage release optionalNo
LockableYes
