Circuit typeMaintained/standby mode
HABSLD EL 3h 32m IR SC/C PM
HANEN10031649
GTIN4015120031649
Connection typePlug connection
Type of wiringSuitable for through wiring
Rated ambient temperature according to IEC62722-2-10 to 40 °C
Operating deviceLED control gear current controlled
Width55 mm
Installation width55 mm
Installation height/depth605 mm
Installation length360 mm
VersionOther
FunctionEscape route marking
Suitable for number of lamps1
Housing colorAluminum
Height/Depth605 mm
Conductor cross-section2.50 mm²
Luminaire with limited surface temperature D-markNo
LampsLED not replaceable
Light distributorOther
Length360 mm
Max. system performance3.0W
With light sourceYes
Mounting typePendulum
Nominal voltage230V
Number of poles7
IP protection)IP40
Protection classI
Voltage typeAC
Cover materialPlastic transparent
Housing materialAluminum
