Gewiss GW90265 (MCB) Compact C-6A 6kA 3-pole 2TE circuit breaker

Gewiss GW90265 (MCB) Compact C-6A 6kA 3-pole 2TE circuit breaker

In stock

SKU: 661982

Price on request

€85.51

€0

Overview

Compact circuit breaker (MCB) according to EN60898-1, with time-delayed thermal overload release and electromagnetic short-circuit release. Alternatively, a RESTART reclosing device RM TOP, a RESTART remote operator CM or two auxiliary devices can be installed on the left side. With label window on the device. Connection (max): flexible 16qmm, rigid 10qmm with insulated plug-in protection. The connection screws can be provided with a sealable cover (order accessories separately). Space-saving series with two protected poles or one protected pole with switched neutral conductor in one division unit. The switching lever can be sealed when switched on or off, or can be locked with a lever lock (order accessories separately) for a padlock.

Property	Value
Triggering characteristics:	C
Rated current:	6 A
Rated voltage:	400 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	2
Number of poles (total):	3
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	72 mm
Protection class (IP):	IP20
Rated switching capacity Icn according to EN 60898 at 230 V:	6 kA
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	10 kA
Rated switching capacity Icu according to IEC 60947-2 at 400 V:	6 kA
Rated switching capacity Icn according to EN 60898 at 400 V:	6 kA
Pollution level:	3
Switching neutral conductor:	no
Number of protected poles:	3
Rated insulation voltage Ui:	500 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 60 °C
Connectable conductor cross-section, stranded:	10 mm²
Connectable conductor cross-section, single-wire:	16 mm²
