Hager MCN516 circuit breaker C16A 1-pole+N 6kA

In stock

SKU: 157646

Price on request

€36.49

€0

Overview

Circuit breaker 1 pole+N 6kA C characteristic 16A 2 modules. Circuit breaker according to DIN0641 part 11/8.92, contact protection IP2x according to DIN0106 part 100 with symbol. Circuit breaker with time-delayed thermal release for overload protection and electromagnetic release for short-circuit protection. Suitable for the subsequent installation of additional equipment. Labeling option directly on the device and individual removal from the phase rail assembly by unlocking the quick-release top hat rail fastening.

Property	Value
Triggering characteristic:	C
Rated current:	16 A
Rated voltage:	230 V
Type of voltage:	AC
Frequency:	50 to 60 Hz
Width in pitch units:	2
Number of poles (total):	2
Energy limitation class:	3
Additional equipment possible:	yes
Overvoltage category:	3
Installation depth:	70 mm
Protection class (IP):	IP20
Rated switching capacity Icn according to EN 60898 at 230 V:	6 kA
Rated switching capacity Icu according to IEC 60947-2 at 230 V:	6 kA
Pollution level:	2
Switching neutral conductor:	yes
Number of protected poles:	1
Rated insulation voltage Ui:	500 V
Rated impulse withstand voltage Uimp:	4 kV
Ambient temperature during operation:	-25 to 70 °C
Connectable conductor cross-section, stranded:	1 to 25 mm²
Connectable conductor cross-section, single-wire:	1 to 35 mm²
