Energy efficiency class of the permanently installed light sourceG
HAN4058075075115
GTIN4058075075115
Covering the luminaire with thermal insulation material possibleNo
Connection typeOther
Type of wiringDiploma
Execution of the gridOther
Rated luminous flux according to IEC 62722-2-1360lm
Rated ambient temperature according to IEC62722-2-1+40°C
Operating deviceElectronic ballast
Suitable for computer workstations according to EN 12464-1No
Width102.0 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature3000K
Color rendering index CRI80-89
Suitable for surface mountingYes
Suitable for ceiling mountingNo
Suitable for flush mountingNo
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorStainless steel
Height/Depth135.0 mm
LED nominal current at constant current60mA
Power factor0.5
Luminaire with limited surface temperature D-markNo
Luminaire luminous efficacy60lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Light distributorOther
Light distributionSymmetrical
Length150.0 mm
Max. system performance6.00W
With operating deviceYes
With motion detectorYes
With light sourceYes
With light sensorYes
With air slotsNo
Nominal voltage240V
Without dimming functionYes
Number of poles2
Impact resistanceIK06
Protection classII
Voltage typeAC
Cover materialPlastic transparent
Housing materialStainless steel
