LEDVANCE Osram LF1300RGBW LF1300RGBW-G1-840-04 8X1

In stock
SKU: 516539
€773.61
Into a basketIn the basketGo

Overview

Product family advantages: Homogeneous color changes. Great design freedom thanks to the flexibility and cuttability of the module. Easy installation and contacting. Protection class: IP00. Tool-free connection using the optional CONNECT system for RGB. Easy installation on many smooth surfaces using the self-adhesive tape on the back. Product family properties: Flexible and divisible LED strip with inline multichip RGB LEDs. RGBW, all types: full individual bins on each color and white. RGB LF200C and LF05CE: binning on white (RGB mix). RGB LF05CA2: binning on individual colors R, G, B. Areas of application: Effect lighting in architecture. Coupling into surface light guides and displays. Dynamic effects in public areas. Technical equipment: Easier connection with optional, matching CONNECT system for RGB. Fast installation with optional SLIM TRACK system.

PropertyValue
Lamp power per meter:17.4 W
With connection set:yes
Length of the individual sections:16.7 mm
Number of lamps per meter:120
Smallest bending radius:20 mm
Width:10.0 mm
Length:3900 mm
Beam angle:120 °
Design:Band
With end piece:no
Color temperature:4000 K
Light source:LED not replaceable
Protection class (IP):IP20
Self-adhesive:yes
Voltage type:DC
Number of bulbs per base:36
Lamp wattage per base:5. W
Luminous flux per meter:1293 lm
Lamp voltage:24 V
Energy efficiency class of the built-in lamp:G
Protection class (NEMA):1
Max. System power:67 W
Light color:RGBW
Color rendering index CRI:80-89
Height/depth:1.40 mm
With protective cover:no
Number of poles:5
Connection type:other

Characteristics

Energy efficiency class of the permanently installed light sourceG
With end pieceNo
With connection setYes
Number of lamps per foot36
ManufacturerLEDVANCE Osram
HAN4052899540620
GTIN4052899540620
Connection typeOther
Number of lamps per meter120
VersionTape
Beam angle120°
Width10.0 mm
Color temperature4000K
Color rendering index CRI80-89
Height/Depth1.40 mm
Smallest bending radius20 mm
Lamp power per meter17.4W
Lamp voltage24V
LampsLED not replaceable
Light colorRGBW
Luminous flux per meter1293lm
Length3900 mm
Length of each section16.7 mm
Max. system performance67W
With protective coverNo
Number of poles5
Self-adhesiveYes
Voltage typeDC
