According to 632 Part 1, Part 2-1 and Part 2-3, IEC 669-1, 669-1-2 and 669-2-3, EN 60 669-1, 60 669-2-1 and 60 669-2-3 Electronic Extremely quiet Exact time setting Can be switched on at any time 100% continuous voltage proof Maximum glow lamp current 50 mA Hand switch for switching from minute light to continuous light Device width 1 division unit 17.5 mm With Lexic system advantages Rex800Plus 230 V, 50/60 Hz Variable connection option With active pre-warning function according to DIN 18015-2, pre-warning function can be switched off using the side setting switch With zero-crossing circuit automatic 3-/4-wire connection identification 0.5-12 min 1 make contact 250 V, 50/60 Hz, 16 A resistive 2000 W incandescent lamp load/halogen lamps 230 V 2000 W low-voltage halogen lamps EVG 1000 VA fluorescent lamps, series compensated 1000 VA parallel compensated max 100 F 1000 W energy saving lamps Advance warning function according to DIN 18015-2 The advance warning function according to DIN 18015-2 is switched on when delivered (circuit diagram 1). The early warning function can be switched off using the side selector switch (circuit diagram 2).
