Legrand 077522 circuit breaker MOSAIC 1+N C16A 2mod ws

Legrand 077522 circuit breaker MOSAIC 1+N C16A 2mod ws

In stock

SKU: 243704

Price on request

€62.13

€0

Into a basketIn the basketGo

Overview

Additional protection LS 16 A, characteristic curve C, 1-pole + connected neutral conductor, color: white

Property	Value
Triggering characteristic:	C
Rated current:	16 A
Rated voltage:	230 V
Type of voltage:	AC
Frequency:	50 Hz
Width in pitch units:	45
Number of poles (total):	2
Installation depth:	40 mm
Protection class (IP):	IP21
Switching neutral conductor:	yes
Number of protected poles:	1
Ambient temperature during operation:	-5 to 40 °C
Connectable conductor cross-section, single-wire:	2.5 mm²

Characteristics

Insert Module TypeLight switch covers

Manufacturer

HAN077522

GTIN3245060775223

Connectable conductor cross-section solid2.5 mm²

Number of protected poles1

Trigger characteristicsC

Rated voltage230V

Rated current16A

Width in pitch units45

Installation depth40 mm

Frequency50Hz

Switching neutral conductorYes

Number of poles (total)2

IP protection)IP21

Voltage typeAC

Ambient temperature during operation-5 to 40 °C
