Legrand 077874 Push button/close Jal Din Prof

Legrand 077874 Push button/close Jal Din Prof

In stock

SKU: 243036

Price on request

€103.44

€0

Into a basketIn the basketGo

Overview

DIN profile step switch 0-1 (SK) Soliroc IP54 IK10 gray

Property	Value
Color:	Chrome
Suitable for protection class (IP):	IP54
Circuit type:	other
Operating type:	Key
Number of actuating rockers:	1
Mounting type:	other
Push button:	no
Composition:	Base element with central cover plate
Fastening type:	other
Material:	Plastic
Material quality:	Thermoplastic
Halogen-free:	yes
Surface:	untreated
Surface finish:	matt
Nominal voltage:	250 V
Switching current for fluorescent lamps:	6 AX
Feedback contact:	no
Washing machine switch:	no
Connection type:	screw terminal
Lighting:	no
Lighting type:	other
Lighting function:	other
Rated current:	6 A
Installation depth:	52 mm
Device depth:	78 mm
Device width:	70 mm
Device height:	70 mm
With mounting plate:	yes
Text field/labeling area:	no
Min. depth of device box:	30 mm

Characteristics

Insert Module TypeLight switch covers

Feedback contactNo

Number of actuating rockers1

Circuit typeOther

LightingNo

Switching current for fluorescent lamps6 AX

Push buttonNo

Washing machine switchNo

Lighting functionOther

Manufacturer

HAN077874

GTIN3245060778743

Connection typeScrew terminal

Surface finishFrosted

Operating modeKey

Mounting typeOther

Rated current6A

Installation depth52 mm

Color

Suitable for protection class (IP)IP54

Device width70 mm

Device height70 mm

Device depth78 mm

Halogen freeYes

Min. depth of the device box30 mm

With mounting plateYes

Mounting typeOther

Nominal voltage250V

SurfaceUntreated

Text field/label areaNo

MaterialPlastic

Material qualityThermoplastic

CompilationBase element with central cover plate

Legrand 077874 Push button/close Jal Din Prof

Legrand 077874 Push button/close Jal Din Prof

Price on request

€103.44

€0

Into a basketIn the basketGo
