Legrand 412075 EMDX³ MID 125A 3-ph.DA RS485+IA 6 energy meters

In stock

SKU: 934814

Price on request

€505.33

€0

Overview

Legrand energy meter EMDX³, MID, 125 A, 3-phase, direct connection, 6-module, with RS485 + pulse output, for measuring the active energy consumed in a 3-phase circuit.

Property	Value
Width in division units:	6
Calibrated:	yes
Pole type:	Four-wire
Meter type:	electronic
Display type:	digital
Mounting type:	REG
Accuracy class:	B
Maximum current (Imax):	125 A
Nominal voltage (Un) NL:	197 to 265 V
Pulse rate:	0.001 to 100 Imp/kWh (kvarh)
Protection class (IP):	IP54
Frequency:	47 to 63 Hz
Tariff design:	Two-tariff
Tariff control:	external
Energy type:	Active and reactive power
Nominal current (In):	20 A
Design:	Direct measurement
Measurement type load profile:	no
EDL40 signature:	no
With lock code:	yes
Pulse type:	S0
Nominal voltage (Un) LL:	340 to 465 V
Number of digits:	8
Suitable for:	Reference
Backstop:	yes
Approval:	Measuring Instruments Directive
Pulse output:	optical
Interface design:	RS-485
