Legrand 775807 insert rocker switch cross, (grey)

In stock

SKU: 243126

Price on request

€12.09

€0

Overview

Rocker switch, non-illuminated, 10/16 AX/250 V, for spread and screw fastening, connections with screwless connection terminals (SL), suitable for connecting rigid and flexible conductors. Fastening with claw and screw. , not illuminable

Property	Value
Color:	gray
Suitable for protection class (IP):	IP21
Circuit type:	Cross switch
Operating type:	Rocker/button
Number of rocker switches:	1
Mounting type:	Flush-mounted
Push button:	no
Composition:	Control element
Fastening type:	Claw/screw fastening
Material:	Plastic
Material quality:	Thermoplastic
Halogen-free:	yes
Surface:	untreated
Surface finish:	matt
RAL number (similar):	7016
Nominal voltage:	250 V
Switching current for fluorescent lamps:	10 AX
Feedback contact:	no
Washing machine switch:	no
Connection type:	other
Lighting:	no
Lighting type:	other
Lighting function:	other
Rated current:	10 A
Installation depth:	21.5 mm
Device depth:	32.5 mm
Device width:	71 mm
Device height:	71 mm
With mounting plate:	yes
Text field/labeling area:	no
Min. Depth of the device box:	30 mm
