METZ CONNECT 15036007609-B OpDAT MV 9xLC-D APC OS2 VIK IP65 surface-mounted housing

In stock
SKU: 1061548
€190.49
Into a basketIn the basketGo

Overview

Surface-mounted housing for the installation and distribution of pre-assembled fiber optic installation cables, equipped with a patch panel with 9xLC-D (green) couplings, protection class: IP65, good access options and easy installation, housings can be arranged in series for larger capacities, cable entries: 12x M12/M16, 2x M20 and M25, flexible cable output for up to 18 cables, compact, simple design, dimensions (L x W x H): 87.5 x 302.5 x 360.0 mm

Property Value
Width: 302.5 mm
Weight: 2.27
Weight unit: KG
Mounting type: Wall mounting
Color: white
Height: 360 mm
Depth: 87.5 mm
RAL number: 9010
With housing: yes
APC version: yes
Suitable for number of couplings/adapters: 9
With front panel: yes
With number of couplings/adapters: 9
Fiber class: OS2
Connector type outside: LC-Duplex
Connector type inside: LC-Duplex
Short description: OpDAT MV 9xLC-D APC OS2 VIK IP65

Characteristics

HABOpDAT MV 9xLC-D APC OS2 VIK IP65
ManufacturerMETZ CONNECT
HAN15036007609-B
GTIN4251394669502
Width302.5 mm
ColorWhite
Weight2,27
Weight unit kg
Height360 mm
Short descriptionOpDAT MV 9xLC-D APC OS2 VIK IP65
Mounting typeWall mounting
RAL number9010
Depth87.5 mm
