PROTEC.class 05105410 PLDS4602K 60mm 4 hole + screw HW-LAN socket

In stock
SKU: 549245
€3.93
Into a basketIn the basketGo

Overview

Hollow wall IT device box For professional installation of network cables in accordance with DIN EN 50173 Guaranteed windproof thanks to 2K technology Automatic compliance with bending radii due to the special design Easy installation due to standard drill hole diameter Depth: 60 mm Material: PP-C Flamm TPE-S Flamm Cable entries: 2x network cable 1x cable Cable retention: Yes Milling hole: 68mm Suitable for wall thickness: 5-25mm Rated voltage: 400V Heavy metal free: Yes DIN EN 60670-1 (VDE 0606-1) DIN EN 60670-22 (VDE 0606-22) Glow wire tested: 850°C Ambient temperature: -25°C to 40°C,

Property Value
With Screws: yes
Max. Conductor cross-section: 1.5 mm²
Sealable: no
Halogen-free: no
Protection class (IP): IP30
Diameter: 68 mm
Mounting type: Hollow wall
Windproof: yes
Can be coupled: yes

Characteristics

HABPLDS4602K 60mm 4 hole + screw
ManufacturerPROTEC.class
HAN05105410
GTIN4016705154104
Diameter68 mm
Halogen freeNo
Mounting typeCavity wall
IP protection)IP30
PROTEC.class 05105410 PLDS4602K 60mm 4 hole + screw HW-LAN socket
PROTEC.class 05105410 PLDS4602K 60mm 4 hole + screw HW-LAN socket
