RZB 982233.002.76 Less is more for LED 33.6W+dimming box DALI LED control gear

RZB 982233.002.76 Less is more for LED 33.6W+dimming box DALI LED control gear

In stock

SKU: 529923

Price on request

€134.92

€0

Overview

Constant voltage converter Touch (Push) DIM Power converter: 35W, Nominal voltage (s): 220, 240 V Nominal frequency (s): 0Hz 50, 60Hz Nominal current: 180 mA Inputs: plug-in terminal Outputs: terminal for LED L: 188mm W: 30mm H: 21mm Degree of protection: IP20 Protection class: II Number of luminaires B10: 13 Number of luminaires B16: 21 Number of luminaires C10: 22 Number of luminaires C16: 35

Property	Value
Output power:	35 W
Protection class (IP):	IP20
Output voltage:	24 V
Output current:	1400 mA
Protection class:	II
Length:	188 mm
Width:	30 mm
Height:	21 mm
Design:	static
Housing:	Plastic housing
Suitable for Outdoor use:	no
Suitable for constant voltage:	yes
Suitable for constant current:	no
Suitable for direct voltage (primary side):	yes
Dimming 0-10 V:	no
Dimming 1-10 V:	no
Dimming DALI:	no
Dimming DSI:	no
DMX dimming:	no
Potentiometer dimming (integrated in the device):	no
GPRS dimming:	no
LineSwitch dimming:	no
Manufacturer-specific dimming:	no
Mains voltage modulation dimming:	no
Phase control dimming:	no
Phase control dimming:	no
Programmable dimming:	no
RF dimming:	no
Sine wave reduction dimming:	no
Touch and dim dimming:	yes
Zigbee dimming:	no
Push button dimming:	yes
Without dimming function:	no
