Schneider Electric 28916 Interpact LT INS 40 3P switch disconnector

Schneider Electric 28916 Interpact LT INS 40 3P switch disconnector

In stock

SKU: 683455

Price on request

€77.30

€0

Into a basketIn the basketGo

Overview

Compact INS40 is a 3-pole, non-automatic load break switch 40A with red rotary handle and yellow front.

Feature	Value
Number of poles:	3.0
Operating power:	20.0 kW
Number of auxiliary contacts as normally closed:	0.0
Number of auxiliary contacts as normally open:	0.0
Number of auxiliary contacts as normally open:	0.0
Number of auxiliary contacts as changeover:	2.0
Rated continuous current Iu:	40.0 A
Max. Rated operating voltage Ue at AC:	500.0 V
Design as EMERGENCY STOP device:	yes
Protection class (IP), front:	IP40
Connection type main circuit:	Screw connection
Device design:	Built-in device, fixed installation technology
Design of the actuating element:	long rotary handle
Suitable for floor mounting:	yes
Conditional Rated short-circuit current Iq:	36.0 kA
Integrated motor drive:	no
Suitable for 4-hole front mounting:	yes
Version as maintenance/repair switch:	yes
Voltage release optional:	no
Suitable for central front mounting:	yes
Suitable for intermediate installation:	no
Suitable for distribution board installation:	yes
Design as main switch:	yes
Design as safety switch:	no
Motor drive optional:	no
Lockable:	yes
Design as reversing switch:	no
Rated short-time withstand current Icw:	3.0 kA
Color of the actuating element:	red
Rated operating voltage:	500.0 V
Number of switches:	1.0
Rated continuous current at AC-23, 400 V:	40.0 A

Characteristics

Number of auxiliary contacts as changeover contacts2.0

HAB28916 Interpact LT INS 40 3P

Manufacturer

HAN28916

GTIN3303430289166

Connection type main circuitScrew connection

Number of auxiliary contacts as normally open0.0

Number of auxiliary contacts as normally closed0.0

Number of switches1.0

Designed as main switchYes

Designed as an EMERGENCY STOP deviceYes

Designed as a safety switchNo

Designed as a maintenance/repair switchYes

Version as reversing switchNo

Design of the actuating elementLong rotary handle

Conditional rated short-circuit current Iq36.0kA

Rated operating voltage500.0V

Rated continuous current Iu40.0A

Rated continuous current at AC-23, 400 V40.0A

Rated short-time withstand current Icw3.0kA

Color of the actuatorRed

Suitable for floor mountingYes

Suitable for front mounting 4-holeYes

Suitable for front mounting CentralYes

Suitable for distribution board installationYes

Suitable for intermediate constructionNo

Device typeBuilt-in device Fixed installation technology

Max. rated operating voltage Ue at AC500.0V

Motor drive integratedNo

Motor drive optionalNo

Number of poles3.0

Protection class (IP), frontIP40

Voltage release optionalNo

LockableYes
